S.S. Micro Cartridge Filter Houshing
Cartridge filter housing system offers wide range of flow capacities & contaminant holding capacities. It’s diameters can accommodate around 1 to 500 cartridges. Cartridge filters are normally used as polishing filter in almost all types of process industries. These filtersare constructed with filter housing, filter cartridges, tube sheet, positive sealing arrangement for cartridge depending upon type of cartridge & choice of end connections. Positive sealing arrangement for cartridge filter assures there is no particle migration or fiber migration, even after high differential pressures.
Features & Advantages
- High dirt holding capacity
- Zero hold-up design
- Permanently piped housing opens without special tools or piping disturbance
- Machined cover gasket groove provides positive O-ring sealing
- Easy to clean
- In-line inlet and outlet with high flow rates and positive sealing to avoid bypassing
- Suitable for Double Open End (DOE), Code 7 (226 O-ring) & 222 O-ring type filter cartridges
- Accommodates 10″, 20″, 30″, 40″, 50″ & 60″ long filter cartridges
- End connections available from ¾″ to 24″ pipe size
- V-posts or threaded center posts
- Quick opening Tri-Clover design
- Easy to operate & low maintenance
- Low downtime
- Flow rate up to 2000 m³/hr & more
- Customized design available
- Housings are permanently piped
Technical Specifications
Sizes (Cartridge Filter Housing Suitable For):
- 1 No. to 500 Nos. of cartridges in a single housing
- Cartridge diameter: 2″, 2.5″, 4″, 6″ & 8″
- Filter cartridge length: 10″, 20″, 30″, 40″, 50″ & 60″
Flow Rate
- Capacity: Up to 2000 m³/hr & more
Material of Construction
- SS 316L
- SS 316
- SS 304
- Super Duplex / Duplex Stainless Steel 2205
- Carbon Steel (All Grades)
- Mild Steel
- Alloy Metals
- Polypropylene
- Lead lining on any metal
- Rubber lining on any metal
Applications
| FCI Code | Description | Style | Material | Size | Design |
|---|---|---|---|---|---|
| FCIMCF-S1-M-203-1-D | SCF – Single Cartridge Filter Housing | S1 – Style -1 | A – SS 304 | 203 – 20" x 3 Nos. of Ø 2.5" | Duplex |
| MCF – Multiple Cartridge Filter Housing | S2 – Style -2 | B – SS 316 | 04 – 20" x 4 Nos. of Ø 2.5" | Simplex | |
| S3 – Style -3 | C – SS 316L | 304 – 20" x 4 Nos. of Ø 2.5" | |||
| D – Carbon Steel | 404 – 20" x 4 Nos. of Ø 2.5" | ||||
| E – CSRL | |||||
| F – ASTM A 106 | |||||
| G – ASTM A 517 | |||||
| H – ASTM A 516 |
